Guangzhou Liuju Beauty Equipment Co., Ltd

1. Working theory:

Cryolipolysis is a beauty treatment that relies on controlled cooling for non-invasive localised fat reduction in problematic areas of the body. It is a way to reshape your clients' contours.

Cavitation is body sculpting with no anesthesia, no scars, no discomfort, no down-time and presents a risk-free alternative to liposuction. The result is instant loss of fat cells.

Radiofrequency treatment is ideal for those who wish to effectively contour the body, reduce fatty deposits and improve the appearance of cellulite.

2. Cryolipolysis features:

1) The current non-surgical medical cosmetic technologies and new hot spot

2) More advanced than liposuction, fat melting technology

3) Europear most popular new way to lose weight

4) Can be up to 26% of the treatment area of new technology to destroy fat

5) Superior RF and ultrasound fat melting technology

3. Preparations before operation:

1) Install the 4 attached caster wheels on the machine, fasten the screws.

2) Install the attached on-hook on the machine, put the probes into the corresponding racks.

3) Before using the cryolipolysis machine, it is required to open the inlet and overflow behind for adding distilled water or purified water.

4) Connect the attached water funnel to the inlet, start adding purified water until water flows out from the overflow, and then close the inlet and over.

5) Check the host power cable is connected.

6) Check the key switch of machine is connected.

4. Technical Parameters:

Voltage: AC220V/110V

Screen: 8 inch TFT color touch screen

Power consumption: ≤800W

Cooling output temperature: -10~4°C

Vacuum: 650mmhg

Cryolipolysis output pressure (vacuum pressure): 0-106kpa

Large cryolipolysis handle: 6.8*10*18.0cm

Small cryolipolysis handle: 5.4*8.0*15.5cm

Cavitation frequency: 40Khz

RF frequency: 5Mhz

Cooling system: water + wind + semiconductor

Working time: continuously / time setting

Gross weight: 39KG

Packing size: 70*50*55CM
